1. Produced of high quality steel，carburize to surface hardness: HRC58～62
2. Parallelism 0.005mm/100mm, squareness 0.005mm
3. Quickly to clamp and easy to operate
4. Used for precision measurement and inspection precision grinding, EDM and wire-cutting machine
5.Guarantee high accuracy in any position
Product brief description
1. Produced of high quality steel，carburize to surface hardness: HRC58～62
2. Parallelism 0.005mm/100mm, squareness 0.005mm
3. Quickly to clamp and easy to operate
4. Used for precision measurement and inspection precision grinding, EDM and wire-cutting machine
5.Guarantee high accuracy in any position
Product specifications
| Model | B | H | H1 | Smax | L | N.W.(kg) |
| mm | mm | mm | mm | mm | ||
| QKG25 | 26 | 9.15 | 29 | 22 | 65.4 | 0.5 |
| QKG36 | 36 | 20 | 45 | 40 | 100 | 1.2 |
| QKG38 | 38 | 20 | 45 | 44 | 105 | 1.3 |
| QKG50 | 50 | 25 | 50 | 65 | 140 | 2 |
| QKG63 | 63 | 32 | 63 | 85 | 175 | 3 |
| QKG73 | 73 | 35 | 67 | 100 | 190 | 4.1 |
| QKG80 | 80 | 40 | 80 | 100 | 200 | 5.5 |
| QKG88 | 88 | 40 | 85 | 125 | 235 | 7.3 |
| QKG100 | 100 | 45 | 90 | 125 | 245 | 10 |
| QKG125 | 125 | 50 | 100 | 160 | 285 | 18 |
| QKG150 | 150 | 50 | 100 | 200 | 330 | 21.5 |
